I’ve had a Raspberry Pie for a while now, and recently picked up a Beaglebone Black.  Unlike the Pi, the BBB has onboard memory and a reasonably fast 1GHz processor.  That means that when I was contemplating setting up a new phone switch, rather than using a computer or the Pi, I bought a new BBB to run it on.  I also got a transparent case for the BBB.

The usual freeware VoIP phone system software is Asterisk.  I run a production Asterisk system for one of my customers with a call center.  I’ve traditionally run my own business’s phone system using Asterisk.  Recently, I’ve been playing more with Freeswitch though.  The main issue with Asterisk is the call logging.  A call comes in to the system with an ID, but it doesn’t keep the same ID- for instance if a call is forwarded between extensions, it gets a new ID, which isn’t related to the old one.  Same thing with going into a call queue- new ID, no relation.  That makes call reporting a bit of a mess if you’re not simply dialing directly into an extension.  Freeswitch by comparison is much, much more logical.

Initially, I tried to build Freeswitch on the default BBB install, but I got some very wonky linker errors.  Rather than spending a few hours trying to track down the issues, I decided to install Debian and follow the instructions at http://www.bobjectsinc.com/tinycomputers/raspberry-pi-vs-beaglebone-black-building-freeswitch/ instead.

Installing Debian was a matter of downloading an install image onto an MMC card, pressing a button and rebooting the BBB.  That installed the OS to the built-in flash, after which I changed the root password.  Then I went to install Freeswitch, and ran out of storage.  So that required mounting the MMC card and using it.  I decided to mount the card on /usr/local since that’s where Freeswitch installs by default.

First, make a partition on the MMC card

# fdisk /dev/mmcblk1
n [for new partition]
p [for primary]
<enter> [default start]
<enter> [default end]
w [write the partition table]
q [quit fdisk]

Next, format the new partition

# mkfs.ext4 /dev/mmcblk1p1

Next, mount the partition on /usr/local

# mount /dev/mmcblk1p1 /usr/local

Then go to that directory

# cd /usr/local

Then we get the Freeswitch source code

# git clone -b v1.2.stable git://git.freeswitch.org/freeswitch.git

After that, we set up the build environment

#apt-get -y install g++ make
#apt-get -y install autoconf automake libtool libncurses5-dev libjpeg-dev liblzo2-2 libpkcs11-helper1 git gawk python-dev libtiff4-dev libperl-dev libgdbm-dev libdb-dev gawk bzip2

Then we build the software

# cd freeswitch
# sh -c './bootstrap.sh && ./configure && make all && make install'
# make cd-sounds-install
# make cd-moh-install

Then we add the following to /etc/fstab

/dev/mmcblk1p1 /usr/local ext4 defaults 0 2

Turn Freeswitch into a service (don’t remember how I did that.)

lynx https://git.kernel.org/cgit/linux/kernel/git/firmware/linux-firmware.git/tree/rtlwifi

cp -pr rtl* /lib/firmware/rtlwifi/

vi /boot/uboot/uEnv.txt

add the line optargs=quiet capemgr.disable_partno=BB-BONELT-HDMI,BB-BONELT-HDMIN

This will disable the HDMI port allowing enough power for the USB WiFi dongle (EDIMAX.)
